Core Dim (H x W)	Overall (H x W)	Hose Locations	Hose Fittings	Fill Neck	Trans Cooler	Mounting Specs	Mounting Type
	19 7/8" x 15 1/4"	26 3/8" x 22 5/8"	In - Center, Out - Driver	In - 1 1/2", Out - 1 3/4	Yes	1/2-20 Straight Thread, Inverted Flare	20 1/2"	Bracket
	Application		Engines				3 Row Core Thickness	3 Row Tank Thickness
	1934 Chevrolet Master		3.4L 207ci L6				2 1/4"	Upper - 2 1/2", Lower - 1 5/8"
	1934 Chevrolet Standard		3.0L 181ci L6
	Note: For a Chevy V8 Conversion
