Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
Fill Neck
Trans Cooler
Mounting Specs
Mounting Type
22" x 16 7/8"
28 1/4" x 19 1/4"
In - Center, Out - Passenger
in - 1 1/2", Out - 1 3/4"
Yes
1/2-20 Straight Thread, Inverted Flare
18 3/8"
Bracket
Application
Engines
3 Row Core Thickness
3 Row Tank Thickness
1938 Chevrolet Master
3.5L 217ci L6
2 1/4"
2 1/2"
Note: For a Chevy V8 Conversion
