CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
Fill Neck
TRANS COOLER
MOUNTING TYPE
21" x 20 1/2"
29 1/2" x 25 3/8"
In - Passenger, Out - Driver
In - 1 1/2", Out - 1 3/4"
Yes
1/8-27 NPT
Bracket
APPLICATION
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
1941 Ford Truck W/ Ford Configuration
2"
3"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 1/8"
