CORE DIM (H x W)	OVERALL (H x W)	HOSE LOCATIONS	HOSE FITTINGS	TRANS COOLER	Fill Neck	MOUNTING TYPE	BRACKET SPECS
	19 3/8 x 20 1/2	26 3/4 x 24 3/4	In - Driver, Out - Passenger	In - 1 1/2, Out - 1 3/4	1/2-20 Straight Thread, Inverted Flare	Yes	Bracket Mount	Horizontal 23 1/2"
	APPLICATION		ENGINES				3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	1949-53 Ford Cars		W/ Chevy Engine, Doesn't Fit Straight 6				2 1/4"	3 7/8"
							2 ROW CORE THICKNESS	2 ROW TANK THICKNESS
							1 5/8"	Upper - 3 7/8", Lower - 2 1/2"
							4 ROW CORE THICKNESS	4 ROW TANK THICKNESS
							2 3/4"	Upper - 3 7/8", Lower - 3 1/8"
