Core Dim (H X W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Type |
BRACKET SPECS |
|
19 3/8 x 20 1/2 |
26 3/4 x 24 3/4 |
In - Passenger, Out - Driver |
In - 1 1/2, Out - 1 3/4 |
Yes |
1/8-27 NPT |
Bracket Mount |
Horizontal 23 1/2" |
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1949 - 1953 Ford Cars |
Ford V8 289ci and 302ci; does not fit Inline 6 Cylinder |
|
2 1/4" |
3 7/8" |
|
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
|
1 5/8" |
Upper - 3 7/8", Lower - 2 1/2" |
|
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
|
2 3/4" |
Upper - 3 7/8", Lower - 3 1/8" |
|
|
|
|
|
|
|
|
|
|
