CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
TRANS COOLER
FILL NECK
MOUNTING TYPE
BRACKET SPECS
16 7/8 x 23 7/8
21 1/2 x 27 1/4
In - Passenger, Out - Driver
In - 1 1/2", Out - 1 1/2"
1/8-27 NPT
Yes
Brackets
26 1/8"
APPLICATION
Engine
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
1981 Jeep CJ5
2.5L L4
2"
2 3/8"
1982 Jeep CJ5
4.2L L6
1981 Jeep CJ7
2.5L L4
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
1982 - 1986 Jeep CJ7
4.2L L6
1 1/2"
2 3/8"
