Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
19 7/8" x 22" |
25 7/8" x 26
1/4" |
In - Driver, Out -
Passenger |
In - 1 3/4",
Out - 2" |
Yes |
1/4-18 NPT |
25 1/4" |
Bracket |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1958 Pontiac Bonneville |
6.1L 370ci V8 |
|
|
|
2" |
Upper - 3
1/8", Lower - 2 3/8" |
|
1958
Pontiac Catalina |
6.1L 370ci V8 |
|
|
|
|
|
|
1958 Pontiac Chieftan |
4.3L 261ci L6, 4.6L 283 V8 |
|
|
|
|
|
|
5.7L 348 V8 |
|
|
|
|
|
|
1958 Pontiac Laurentian |
4.3L 261ci L6, 4.6L 283 V8 |
|
|
|
|
|
|
1958 Pontiac Pathfinder |
4.3L 261ci L6, 4.6L
283 V8 |
|
|
|
|
|
|
1958 Pontiac Star Chief |
4.3L 261ci L6, 6.1L
370ci V8 |
|
|
|
|
|
|
1958 Pontiac Strato-Chief |
4.3L 261ci L6, 4.6L 283 V8 |
|
|
|
|
|
|
5.7L 348ci V8, 6.1L 370ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
