Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 3/4" x 25 1/2" |
23 1/2" x 28
1/4" |
In - Center, Out -
Drive |
In - 1 3/4",
Out - 1 3/4" |
Yes |
5/8-18 UNF |
27 3/8" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
Note: Mounting brackets on Grill side of
radiator |
|
1959 - 1960 Cadillac Commercial Chassis |
6.4L 390ci V8 |
|
|
|
1959 - 1960
Cadillac DeVille |
6.4L 390ci V8 |
|
|
|
|
|
|
1959 - 1960
Cadillac Eldorado |
6.4L 390ci V8 |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1959 - 1960
Cadillac Series 60 Fleetwood |
6.4L 390ci V8 |
|
|
|
2 1/4" |
2 1/2" |
|
1959 - 1960
Cadillac Series 62 |
6.4L 390ci V8 |
|
|
|
|
|
|
1959 - 1960
Cadillac Series 75 Fleetwood |
6.4L 390ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
