Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 1/2" x 25 1/8" |
22 7/8" x 25
1/4" |
In - Driver, Out -
Passenger |
In - 1 3/4",
Out - 1 3/4" |
Yes |
1/2-20 Straight
Thread, Inverted Flare |
N/A |
Saddle Mount |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1961 - 1964 Pontiac Bonneville |
6.4L 389ci V8, 6.9L
421ci V8 |
|
|
2" |
2 3/8" |
|
1961-1964 Pontiac Catalina |
6.4L 389ci V8, 6.9L 421ci V8 |
|
|
|
|
|
1962 - 1964 Pontiac Grand Prix |
6.4L 389ci V8, 6.9L
421ci V8 |
|
|
4 Row Core Thickness |
4 Row Tank Thickness |
|
1961 - 1964 Pontiac Star Chief |
6.4L 389ci V8, 6.9L
421ci V8 |
|
|
2 3/4" |
Upper - 3
1/8", Lower - 2 1/4" |
|
1961 Pontiac Ventura |
6.4L 389ci V8, 6.9L
421ci V8 |
|
|
|
Note: Lower Tank Tapered to 2 1/4" |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
