CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
Fill Neck |
TRANS COOLER |
MOUNTING TYPE |
|
17 x 22 1/2 |
21 1/2 x 27 1/8 |
In - Passenger, Out - Driver |
In - 1 3/4, Out - 1 3/4 |
No |
1/8-27 NPT |
Saddle Mount |
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
1964 Ford Galaxie 500 |
4.7L 289ci V8, 5.8L 352ci V8 |
|
|
2 1/4 |
2 1/2 |
|
6.4L 390ci V8 |
|
|
|
|
|
1964-1966
Mercury Montclair |
6.4L 390ci V8, 6.7L 410ci V8 |
|
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
|
7.0L 427ci V8, 7.0L 428ci V8 |
|
|
2 3/4 |
3 1/8 |
|
1964-1966
Mercury Monterey |
6.4L 390ci V8, 6.7L 410ci V8 |
|
|
|
|
|
7.0L 427ci V8, 7.0L 428ci V8 |
|
|
1964-1966
Mercury Park Lane |
6.4L 390ci V8, 6.7L 410ci V8 |
|
|
7.0L 427ci V8, 7.0L 428ci V8 |
|
|
|
|
|
|
|
|
|
|
