Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
16 7/8" x 24 1/2" |
19 1/8" x 29 7/8" |
In - Passenger, Out - Driver |
In - 1 1/4", Out - 1 1/2" |
Yes |
1/4-18 NPT |
N/A |
Pin Mount |
|
|
APPLICATION |
ENGINES |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
Ford Thunderbird - 1980-88 |
200ci L6, 255ci V8, 302ci V8 |
|
2 1/2" |
2 3/4" |
|
Lincoln Zephyr - 1980-83 |
|
|
|
Mercury Marquis - 1983 |
140ci L4, 200ci L6, 232ci V6 |
|
|
Mercury Marquis - 1984 |
140ci L4, 232ci V6 |
|
|
Mercury Marquis - 1985 |
140ci L4, 232ci V6, 323ci V8 |
|
|
Mercury Marquis - 1986 |
140ci L4, 232ci V6 |
|
|
Mustang - 1979-93 |
All |
|
|
Lincoln Continental 1982-87 |
All |
|
|
Lincoln Mark VII - 1984-92 |
302 |
|
|
Ford LTD 1983-86 |
All |
|
|
Ford Granada 1981-82 |
All |
|
|
Mercury Cougar/ XR7 1980-88 |
All |
|
|
Ford Futura/ Fairmont 1980-83 |
All (inc Turbo) |
|
|
Mercury Capri 1980-86 |
All (inc Turbo) |
|
|
Mercury Monarch 1975-80 |
Needs a Hose Adapter |
|
|
Ford Granada 1975-80 |
Needs a Hose Adapter |
|
|
Lincoln Versailles 1977-80 |
Needs a Hose Adapter |
|
|
|
|
|
|
|
|
|
|
|
