CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
Fill Neck |
MOUNTING TYPE |
Mounting Specs |
|
17 x 26 1/4 |
18 1/4 x 31 5/8 |
In-Passenger, Out-Passenger |
In/Out: -16ORB (Female) |
Yes |
Saddle Mount |
N/A |
|
|
LS Engine Swap And Dual Pass for All Engines
Below |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
|
2 1/4" |
2 1/2" |
|
|
BUICK APPLICATION |
ENGINES |
|
|
Buick Apollo - 1975 |
4.1l L6, 350ci V8 |
|
|
Buick Century - 1977 |
305ci v8 |
|
|
Buick Century - 1978 |
3.2l V6, 3.8l V6 |
|
|
Buick Century - 1979 |
3.2l V6, 3.8l V6, 301ci V8 |
|
|
Buick Century - 1980 |
265ci V8, 301ci V8, 305ci V8 |
|
|
Buick Century - 1981 |
265ci V8, 267ci V8, 305ci V8, 350ci V8 |
|
|
Buick LeSabre - 1980 |
301ci V8 |
|
|
Buick Regal - 1978 |
3.2l V6, 3.8l V6, 305ci V8 |
|
|
Buick Regal - 1979 |
3.2l V6, 3.8l V6, 301ci V8, 305ci V8 |
|
|
Buick Regal - 1980 |
301ci V8, 305ci V8 |
|
|
Buick Regal - 1981 |
4.4l V6, 4.4l V6 |
|
|
Buick Regal - 1982 |
4.4l V6, 305ci V8 |
|
|
Buick Regal - 1983-85 |
305ci V8 |
|
|
Buick Regal - 1986-87 |
305ci V8, 307ci V8 |
|
|
Buick Skylark - 1975 |
3.8l V6, 260ci V8, 350ci V8 |
|
|
Buick Skylark - 1976-79 |
3.8l V6, 260ci V8, 350ci V8 |
|
|
CADILLAC APPLICATION |
ENGINES |
|
|
Cadillac Seville - 1976-79 |
350ci V8 |
|
|
CHEVY APPLICATION |
ENGINES |
|
|
Chevy Blazer/Jimmy - 1973 |
4.1l L6, 4.8l L6 |
|
|
Chevy Blazer/Jimmy - 1974-79 |
4.1l L6 |
|
|
Chevy Blazer/Jimmy - 1980 |
4.1l L6, 305ci V8, 350ci V8 |
|
|
Chevy Camaro - 1970-71 |
4.1l L6, 307ci V8, 350ci V8 |
|
|
Chevy Camaro - 1972-73 |
307ci V8, 350ci V8 |
|
|
Chevy Camaro - 1974 |
350ci V8 |
|
|
Chevy Camaro - 1975 |
4.1l L6, 350ci V8 |
|
|
Chevy Camaro - 1976-79 |
4.1l L6, 305ci V8, 350ci V8 |
|
|
Chevy Camaro - 1980-81 |
267ci V8, 305ci V8, 350ci V8 |
|
|
Chevy Caprice - 1980-85 |
305ci V8, 350ci V8 |
|
|
Chevy Caprice - 1986 |
305ci V8, 307ci V8, 350ci V8 |
|
|
Chevy C/K Series - 1973-79 |
4.1l L6, 4.8l L6 |
|
|
Chevy C/K Series - 1980 |
4.1l L6, 4.8l L6, 305ci V8, 350ci V8 |
|
|
Chevy El Camino/Cabellero - 1978-79 |
3.3l V6, 3.8l V6, 305ci V8, 350ci V8 |
|
|
Chevy El Camino/Cabellero - 1980-82 |
267ci V8, 305ci V8 |
|
|
Chevy El Camino/Cabellero - 1983 |
305ci V8 |
|
|
Chevy El Camino/Cabellero - 1984-87 |
305ci V8 |
|
|
Chevy Impala - 1980-85 |
305ci V8, 350ci V8 |
|
|
Chevy Malibu - 1978 |
3.3l V6, 3.8l V6, 305ci V8,350ci V8 |
|
|
Chevy Malibu - 1979 |
3.3l V6, 3.8l V6 267ci V8, , 305ci V8,350ci V8 |
|
|
Chevy Malibu - 1980 |
267ci V8, 305ci V8, 350ci V8 |
|
|
Chevy Malibu - 1982 |
267ci V8, 305ci V8 |
|
|
Chevy Malibu - 1983 |
305ci V8 |
|
|
Chevy Monte Carlo - 1978 |
3.3l V6, 3.8l V6, 305ci V8 |
|
|
Chevy Monte Carlo - 1979 |
3.3l V6, 3.8l V6, 267ci V8, 305ci V8 |
|
|
Chevy Monte Carlo - 1980-82 |
267ci V8, 305ci V8 |
|
|
Chevy Monte Carlo - 1983-87 |
305ci V8 |
|
|
Chevy Nova - 1975-79 |
4.1l L6, 262ci V8, 350ci V8 |
|
|
Chevy S/T series - 1973 |
4.1l L6, 4.8l L6 |
|
|
Chevy S/T series - 1974-79 |
4.1l L6 |
|
|
Chevy S/T series - 1980 |
4.1l L6, 305ci V8, 350ci V8 |
|
|
Chevy Suburban - 1976-78 |
305ci V8, 350ci V8 |
|
|
Chevy Suburban - 1979-80 |
350ci V8 |
|
|
OLDS APPLICATION |
ENGINES |
|
|
Olds 98 - 1977-80 |
350ci V8 |
|
|
Olds Cutlass - 1978-79 |
3.8l L6, 260ci V8, 305ci V8, 350ci V8 |
|
|
Olds Cutlass - 1980 |
260ci V8, 305ci V8, 350ci V8 |
|
|
Olds Cutlass - 1981 |
260ci V8, 267ci V8 |
|
|
Olds Cutlass - 1982 |
Engines |
|
|
Olds Cutlass - 1983 |
Not |
|
|
Olds Cutlass - 1984 |
Listed |
|
|
Olds Cutlass - 1985-87 |
305ci V8, 307ci V8 |
|
|
Olds Cutlass Calais - 1978-79 |
305ci V8 |
|
|
Olds Cutlass Calais - 1980 |
3.8l LV6, 260ci V8, 305ci V8, 350ci V8 |
|
|
Olds Cutlass Calais - 1981 |
260ci V8 |
|
|
Olds Cutlass Calais - 1982 |
267ci V8, 307ci V8 |
|
|
Olds Cutlass Calais - 1983 |
307ci V8 |
|
|
Olds Cutlass Calais - 1984 |
305ci V8, 307ci V8 |
|
|
Olds Cutlass Cruiser - 1978-79 |
3.8l V6, 260ci V8, 305ci V8, 350ci V8 |
|
|
Olds Cutlass Cruiser - 1980-81 |
260ci V8, 305ci V8, 350ci V8 |
|
|
Olds Cutlass Cruiser - 1982 |
260ci V8, 267ci V8, 305ci V8, 307ci V8 |
|
|
Olds Cutlass Cruiser - 1983 |
305ci v8, 307ci V8 |
|
|
Olds Cutlass Supreme - 1978-79 |
3.8l V6, 260ci V8, 305ci V8, 350ci V8 |
|
|
Olds Cutlass Supreme - 1980 |
260ci V8, 305ci V8, 350ci V8 |
|
|
Olds Cutlass Supreme - 1981 |
260ci V8, 350ci V8 |
|
|
Olds Cutlass Supreme - 1982 |
260ci V8, 267ci V8, 307ci V8 |
|
|
Olds Cutlass Supreme - 1983 |
305ci V8, 307ci V8 |
|
|
Olds Cutlass Supreme - 1988 |
307ci V8 |
|
|
Olds Delta 88 - 1980 |
260ci V8 |
|
|
Olds Eighty Eight/Royal - 1980 |
260ci V8 |
|
|
Olds Omega - 1975-76 |
4.1l L6, 350ci V8 |
|
|
Olds Omega - 1977-79 |
3.8l V6, 305ci v8, 350ci V8 |
|
|
PONTIAC APPLICATION |
ENGINES |
|
|
Pontiac Bonneville - 1980 |
3.8l V6 |
|
|
Pontiac Bonneville - 1981 |
265ci V8 |
|
|
Pontiac Bonneville - 1983-86 |
305ci V8 |
|
|
Pontiac Catalina - 1965-66 |
ALL |
|
|
Pontiac Catalina - 1980 |
3.8l V6 |
|
|
Pontiac Catalina - 1981 |
265ci V8 |
|
|
Pontiac Grand Am - 1978 |
301ci V8, 305ci V8 |
|
|
Pontiac Grand Am - 1979 |
3.8l V6, 301ci V8, 305ci V8 |
|
|
Pontiac Grand Am - 1980 |
301ci V8, 305ci V8 |
|
|
Pontiac Grand Le Mans - 1975 |
4.1l L6, 350ci V8, 400ci V8, 455ci V8 |
|
|
Pontiac Grand Le Mans - 1976 |
4.1l L6, 260ci V8, 305ci V8, 350ci V8, 400ci
V8, 455ci V8 |
|
|
Pontiac Grand Le Mans - 1977 |
3.8l V6 4.1l L6, 301ci V8, 305ci V8, 350ci V8,
400ci V8, 403ci V8 |
|
|
Pontiac Grand Le Mans - 1978 |
3.8l V6, 305ci v8, 350ci V8 |
|
|
Pontiac Grand Le Mans - 1979-80 |
3.8l V6, 301ci V8, 305ci v8, 350ci V8 |
|
|
Pontiac Grand Prix - 1978-79 |
3.8l V6, 301ci V8, 305ci V8 |
|
|
Pontiac Grand Prix - 1980-81 |
265ci V8, 301ci V8, 305ci V8 |
|
|
Pontiac Grand Prix - 1983-86 |
305ci V8 |
|
|
Pontiac Le mans - 1978 |
3.8l V6, 305ci v8, 350ci V8 |
|
|
Pontiac Le mans - 1981 |
3.8l V6, 265ci V8, 301ci V8, 305ci V8 |
|
|
Pontiac Parisienne - 1984-85 |
305ci V8 |
|
|
Pontiac Parisienne - 1986 |
305ci V8, 307ci V8 |
|
|
Pontiac Pheonix - 1978-79 |
3.8l V6, 305ci V8 |
|
|
Pontiac Ventura - 1975-76 |
4.1l L6, 350ci V8 |
|
|
Pontiac Ventura - 1977 |
3.8l V6, 301ci V8 |
|
|
|
|
|
|
|
|
|
|
