Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
16 1/4" x 24 3/4 |
21 1/2" x
28" |
In - Passenger, Out
- Passenger |
In - 1 1/4",
Out - 1 1/2" |
Yes |
1/2-20 Straight
Thread, Inverted Flare |
26 7/8" |
Brackets |
|
|
|
|
|
|
|
|
|
|
LS Engine Swap for All Engines Below |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
|
|
2 1/2" |
2 3/4" |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
|
|
|
1963 - 1965 Chevrolet Bel Air |
3.8L 230ci L6, 4.1L
250ci L6, |
|
|
|
|
|
|
4.6L 283ci V8, 5.3L 327ci V8 |
|
|
|
|
|
|
1960 - 1965 Chevrolet Biscayne |
3.8L 230ci L6, 3.9L 236ci L6, |
|
|
|
|
|
|
4.1L 250ci L6, 4.6L 283ci V8 |
|
|
|
|
|
|
5.3L 237ci V8 |
|
|
|
|
|
|
1964 - 1965 Chevrolet Chevelle |
3.2L 194ci L6, 3.8L 230ci L6, |
|
|
|
|
|
|
4.6L 283ci V8, 5.3L 327ci V8 |
|
|
|
|
|
|
1959 - 1965 Chevrolet El Camino |
3.2L 194ci L6, 3.8L 230ci L6, |
|
|
|
|
|
|
4.6L 283ci V8, 5.3L 327ci V8 |
|
|
|
|
|
|
1959 - 1963 Chevrolet Impala |
3.8L 230ci L6, 4.6L 283ci V8, |
|
|
|
|
|
|
5.3L 327ci V8 |
|
|
|
|
|
|
1959 - 1961 Cheverolet Kingswood |
3.8L 230ci L6, 4.6L 283ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
