CORE DIM (H x W)	OVERALL (H x W)	HOSE LOCATIONS	HOSE FITTINGS	TRANS COOLER	Fill Neck	MOUNTING TYPE	BRACKET SPECS
	16 1/8 x 19 5/8	21 x 22 1/4	In - Passenger, Out - Driver	In 1-1/4, Out 1-1/4	1/8-27 NPT	Yes	Bracket Mount	21 1/8"
	APPLICATION		ENGINES				3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	Ford Mustang 1967-70		Straight Six				2"	2 3/8"
	Ford Maverick - 1970-73		Straight Six
	Mercury Comet - 1971-72		Straight Six
