Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
|
17" x 20 3/4" |
19 1/4" x 28 3/4" |
In - Driver, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
Yes |
No |
27 1/4" |
Flanges |
|
|
|
|
|
|
|
|
|
|
|
|
This Part is Manual Transmission Only |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
|
|
B CORE 2 1/2" |
2 3/4" |
|
|
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
|
|
|
1967 - 1969
Chevy Camaro (Small Block) |
4.1L L6, 305ci V8, 307ci V8, 327ci V8, 350ci V8 |
|
|
|
|
|
|
1967 - 1969
Pontiac Firebird/Trans Am |
4.1L L6, 305ci V8, 307ci V8, 327ci V8, 350ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
