CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
FILL NECK |
MOUNTING TYPE |
BRACKET SPECS |
|
17 x 20 3/4 |
19 1/4 x 28 3/4 |
In - Passenger, Out - Passenger |
In/Out: -16ORB (Female) |
No |
Yes |
Flanges |
Horizontal - 27 1/4 |
|
|
APPLICATION |
ENGINES |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
Chevy Camaro (Small Block) - 1967-69 |
4.1L L6, 305ci V8, 307ci V8, 327ci V8, 350ci V8 |
|
B CORE 2 1/2" |
2 3/4" |
|
Pontiac Firebird/Trans Am - 1967-69 |
4.1L L6, 305ci V8, 307ci V8, 327ci V8, 350ci V8 |
|
|
|
|
NOTE: Can be used as a crossflow
for all 281 and 289 applications. Will not fit Factory Shroud for 281 and 289
applications |
|
|
|
|
|
|
|
|
|
|
|
LS Engine Swap And Dual Pass for All Engines
Below |
|
|
|
|
|
|
|
|
|
|
|
|
|
