CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
TRANS COOLER |
MOUNTING TYPE |
| |
17 x 26 1/4 |
19 1/4 x 32 |
In - Driver, Out - Passenger |
In - 1 1/2, Out - 1 3/4 |
Yes |
1/2-20 Straight Thread,
Inverted Flare |
Saddle Mount |
| |
|
|
|
|
|
|
|
| |
APPLICATION |
ENGINES |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
| |
1969-72
Chevrolet S/T Series Pickups/Blazers |
4.1L/250 ci/L6 |
|
2 1/4" |
2 1/2" |
| |
1968-71
Chevrolet G-Series Van |
4.1L/250 ci/L6 |
|
|
|
| |
1967-72
Chevrolet C/K Series Pickup |
4.1L 250ci L6/ 4.6L 283ci V8/ 4.8L 292ci L6/
5.4L 327ci V8 |
|
|
|
| |
1969-72
Chevrolet Blazer/Jimmy |
4.1L/250 ci/L6 |
|
|
|
| |
1967
Chevrolet 40/50/60/ Conv/School Bus |
4.8L/292 ci/L6 |
|
|
|
| |
1970-72
Chevrolet P Series Motor Homes/Vans |
4.8L/292 ci/L6 |
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
