CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
TRANS COOLER |
MOUNTING TYPE |
|
17 x 28 1/4 |
19 1/4 x 34 |
In-Passenger, Out-Passenger |
In/Out: -16ORB (Female) |
Yes |
No |
Saddle Mount |
|
|
APPLICATION |
ENGINES |
|
LS Engine Swap And Dual Pass for
All Engines Below |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
Chevy
Blazer / Jimmy - 1967-71 |
350ci V8 |
|
|
2 1/4" |
2 3/4" |
|
Chevy
Blazer / Jimmy - 1972 |
307ci V8, 350ci V8 |
|
|
|
Chevy C/K
Series - 1967 |
307ci V8, 396ci V8 |
|
|
|
Chevy C/K
Series - 1969 |
307ci V8, 350ci V8, 396ci V8 |
|
|
|
Chevy C/K
Series - 1970-72 |
307ci V8, 350ci V8 |
|
|
|
Chevy S/T
Series - 1967-71 |
350ci V8 |
|
|
|
Chevy S/T
Series - 1972 |
307ci V8, 350ci V8 |
|
|
|
Chevy
Suburban - 1967 |
4.1l L6, 4.8l L6, 307ci V8 |
|
|
|
Chevy
Suburban - 1967-72 |
4.1l L6, 4.8l L6, 307ci V8,
350ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
