CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
FILL NECK |
MOUNTING TYPE |
BRACKET SPECS |
|
17 x 23 |
19 1/4 x 30 1/4 |
In-Passenger, Out-Passenger |
In/Out: -16ORB (Female) |
No |
Yes |
Bracket Mount |
Horizontal - 29 1/8 |
|
|
APPLICATION |
ENGINES |
|
LS Engine Swap And Dual Pass for
All Engines Below |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
Camaro (Big Block) 1967-1969 |
5.7, V8 |
|
|
B CORE 2 1/2" |
2 3/4" |
|
Firebird/Trans AM 1967-69 |
5.2/5.7 V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
