Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans
Cooler |
Mounting Specs |
Mounting Type |
|
17 1/2" x 26 1/8" |
23 1/2" x 29" |
In - Passenger, Out - Driver |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/8-27 NPT |
Bracket Mount |
Vert - 13 5/8" Horizontal - 28" |
|
|
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
CAN BE USED AS DPI #332 W/ FAN COMBO ONLY |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1970 - 1974
Dodge Challenger |
ALL BIG BLOCKS |
|
|
B CORE 2 1/2" |
2 3/4" |
|
1968 - 1973
Dodge Charger |
ALL BIG BLOCKS |
|
|
|
|
|
|
|
|
1968 - 1973
Dodge Coronet |
ALL BIG BLOCKS |
|
NOTE: VERIFY HOSE CONFIGURATIONS AND CORE
SIZE |
|
|
|
|
1970 - 1973
Plymouth Barracuda |
ALL BIG BLOCKS |
|
|
|
|
|
1970
Plymouth Belvedere |
ALL BIG BLOCKS |
|
|
|
|
|
|
|
|
1968 - 1972
Plymouth GTX |
ALL BIG BLOCKS |
|
|
|
|
|
|
|
|
1968 - 1973
Plymouth Roadrunner |
ALL BIG BLOCKS |
|
|
|
|
|
|
|
|
1968 - 1973
Plymouth Satellite |
ALL BIG BLOCKS |
|
|
|
|
|
|
|
|
DODGE CHARGERS & CORONETS CAN BE USED
BACK TO 1968 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
