CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

FILL NECK

MOUNTING TYPE

16 1/2" x 21 3/4"

18 7/8" x 27 3/8"

In - Passenger, Out - Driver

In - 1 1/2, Out - 1 1/2

1/8-27 NPT

Yes

Saddle Mount

APPLICATION

ENGINES

Can use DPI # 382, 384, 385, 386

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

LTD 1968

6.4 V8

2 1/4"

2 1/2"

COLONY PARK 1967-68

MARQUIS 1967-68

6.4/7.0 V8

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

THUNDERBIRD 1967-68

1 1/2"

COUNTRY SEDAN 1968

6.4/7.0 V8

GALAXIE 1968

6.4/7.0 V8

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

2 3/4"

3 1/8"
