Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Trans Cooler |
Fill Neck |
Mounting Type |
Bracket Specs |
|
19 1/4 x 26 3/8 |
26 3/8 x 29 1/2 |
In - Passenger, Out - Driver |
In - 1 3/4, Out - 2 |
1/8-27 NPT |
Yes |
Bracket Mount |
Vert - 16 1/2 Horizontal - 27 3/8 |
|
|
APPLICATION |
ENGINES |
|
2 Row Core Thickness |
2 Row Tank Thickness |
|
Ford Bronco - 1978-79 |
351ci V8, 400ci V8 |
|
1 1/2" |
2 1/2" |
|
Ford F Series Truck - 1968-69 |
360ci V8, 390ci V8 |
|
|
Ford F Series Truck - 1970-72 |
360ci V8, 390ci V8 |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
Ford F Series Truck - 1973-75 |
302ci V8, 360ci V8, 390ci V8 |
|
B CORE 2 1/2" |
2 3/4" |
|
Ford F Series Truck - 1976 |
302ci V8, 351ci V8 |
|
|
Ford F Series Truck - 1977-79 |
302ci V8, 351ci V8, 400ci V8 |
|
4 Row Core Thickness |
4 Row Tank Thickness |
|
ALSO FITS DPI APPLICATION 132 |
|
2 3/4" |
3 1/4" |
|
|
|
DOES NOT FIT INLINE 6 CYLINDER
MOTOR, V8 ONLY |
|
|
|
|
|
|
|
|
|
|
|
|
|
