Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
19 1/4" x 25 1/2" |
25 3/4" x 29
7/8" |
In - Passenger, Out
- Driver |
In - 1 3/4",
Out - 2" |
Yes |
1/8 - 27NPT |
28 7/8" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1966 - 1976 Ford F-100 |
5.8L 352ci V8, 5.9 360ci V8, 6.4L 390ci V8 |
|
|
2 1/2" |
2 7/8" |
|
1976 - 1977 Ford F-150 |
5.8L 351ci V8, 5.8L 352ci V8, 5.9 360ci V8, 6.6L 400ci V8 |
|
|
|
|
|
1966 - 1977 Ford F-250 |
5.8L 351ci V8, 5.8L 352ci V8, 5.9 360ci V8, 6.4L 390ci V8, 6.6L 400ci
V8 |
|
|
|
|
|
1966 - 1974 Ford F-350 |
5.8L 352ci V8, 5.9 360ci V8, 6.4L 390ci V8 |
|
|
|
|
|
Radiator mounting brackets on
engine side of radiator. For vehicles that use grill side mounting brackets,
see Part# 433B |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
