Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 7/8' x 20 3/4" |
23 3/8" x 25 5/8" |
In - Driver, Out - Passenger |
In - 1 1/2", Out 1 3/4" |
Yes |
1/8-27 NPT |
24 5/8" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
Dodge |
|
|
2 1/4" |
Upper - 3 1/8", Lower - 2 1/2" |
|
1975 - 1978
Dodge B100 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1971 - 1974
Dodge B100 Van |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
2 Row Core Thickness |
2 Row Tank Thickness |
|
1975 - 1978
Dodge B200 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
1 5/8" |
Upper - 3 1/8", Lower - 2" |
|
1971 - 1974
Dodge B200 Van |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1975 - 1978
Dodge B300 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1971 - 1974
Dodge B300 Van |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1974 - 1978
Dodge CB300 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1970 - 1974
Dodge Challenger |
5.2L 318ci V8, 5.6L 340ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1971 - 1974
Dodge Charger |
5.2L 318ci V8, 5.6L 340ci V8 |
|
|
|
|
|
1971 - 1973 Dodge Coronet |
3.7L 225ci L6, 5.2L 318ci V8, 5.6L 340ci V8 |
|
|
|
|
|
5.9L 340ci V8, 6.3L 383ci V8, 6.6L 400ci V8 |
|
|
|
|
|
7.0L 426ci V8, 7.2L 440ci V8 |
|
|
|
|
|
1975 - 1979
Dodge D100 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1976 - 1979
Dodge D100 Panel |
5.9L 360ci V8 |
|
|
|
|
|
1972 - 1974
Dodge D100 Pickup |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1977 - 1979
Dodge D150 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1975 - 1979
Dodge D200 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1975 - 1979
Dodge D300 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1979 Dodge
D400 |
5.9L 360ci V8 |
|
|
|
|
|
1979 Dodge
D450 |
5.9L 360ci V8 |
|
|
|
|
|
1974 - 1979
Dodge Ramcharger |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1979 Dodge
RD200 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1975 - 1977
Dodge W100 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1972 - 1974
W100 Pickup |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1977 - 1979
Dodge W150 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1975 - 1979
Dodge W200 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1972 - 1974
Dodge W200 Pickup |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1975 - 1979
Dodge W300 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1972 - 1974
Dodge W300 Pickup |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
Fargo |
|
|
|
|
|
1971 - 1972
Fargo B100 Van |
5.2L 318ci V8 |
|
|
|
|
|
1971 - 1972
Fargo B200 Van |
5.2L 318ci V8 |
|
|
|
|
|
1971 - 1972
Fargo B300 Van |
5.2L 318ci V8 |
|
|
|
|
|
1972 Fargo
D100 Pickup |
5.2L 318ci V8 |
|
|
|
|
|
1972 Fargo
W100 Pickup |
5.2L 318ci V8 |
|
|
|
|
|
1972 Fargo
W200 Pickup |
5.2L 318ci V8 |
|
|
|
|
|
Plymouth |
|
|
|
|
|
1970 - 1973
Plymouth Barracuda |
5.2L 318ci V8, 5.6L 340ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1970
Plymouth Belvedere |
5.2L 318ci V8 |
|
|
|
|
|
1975 - 1978
Plymouth PB100 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1974
Plymouth PB100 Van |
5.2L 318ci V8 |
|
|
|
|
|
1975 - 1978
Plymouth PB200 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1974
Plymouth PB200 Van |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1975 - 1978
Plymouth PB300 |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1974
Plymouth PB300 Van |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1971 - 1973
Plymouth Roadrunner |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1972
Plymouth Satelite |
5.2L 318ci V8, 5.6L 340ci V8, 5.9L 360ci V8 |
|
|
|
|
|
1974 - 1979
Plymouth Trailduster |
5.2L 318ci V8, 5.9L 360ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
