CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

FILL NECK

MOUNTING TYPE

19 1/8 x 19

21 x 26 3/8

In - Driver, Out - Passenger

In - 1 1/2, Out - 1 3/4

1/8-27 NPT

Yes

Saddle Mount

APPLICATION

ENGINES

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

Ford Bronco - 1966-77

302ci V8

2 1/4"

2 1/2"

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

1 5/8"

2"

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

2 3/4"

3 1/8"
