Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17" x 20 3/4" |
19" x 27 1/4" |
In - Driver, Out - Passenger |
In - 1 1/2", Out - 1 1/2" |
Yes |
No |
N/A |
Saddle Mount |
|
|
|
|
|
|
|
|
|
|
This Part is Manual Transmission Only |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
|
2 1/4" |
2 1/2" |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
|
|
Buick Apollo - 1973-74 |
4.1l 250 L6 |
|
|
|
|
|
Buick Century -1977 |
5.0l 305 V8, 5.7l 350 V8 |
|
|
|
|
|
Buick Century - 1979-81 |
3.2l 196 V6, 3.8l 231 V6, |
|
|
|
|
|
Buick Le Sabre - 1965 |
4.9l 300 V8 |
|
|
|
|
|
Buick Le Sabre - 1980-85 |
3.8l 231 V6 |
|
|
|
|
|
Buick Skylark-1977-79 |
5.0l 305 V8 |
|
|
|
|
|
Buick Skylark-1965-69 |
3.7l 225 V6, 4.9l 300 V8, 6.6l 401 V8, 4.1l 250
L6 |
|
|
|
|
|
Buick Skylark-1967 |
6.6l 401 V8 |
|
|
|
|
|
Buick Regal - 1980-87 |
3.8l 231 V6, 4.1l 252 V6
(Non-Turbo) |
|
|
|
|
|
Chevy Biscayne-1971-1972 |
4.1l 250 L6 |
|
|
|
|
|
Chevy Bel-Air - 1971-73 |
4.1l 250 L6, 5.7l 350 V8 |
|
|
|
|
|
Chevy Chevelle - 1968-71 |
4.1l 250 L6 |
|
|
|
|
|
Chevy Camaro-1972-1977 |
4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8, 5.0l 305
V8 |
|
|
|
|
|
Chevy Camaro - 1972-81 |
4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8, 5.0l 305
V8, 3.8l 229 V6, 3.8l 231 V6, 4.4l 267 V8 |
|
|
|
|
|
Chevy Caprice - 1980-86 |
3.8l 229 V6, 3.8l 231 V6, 4.3l 262 V6 |
|
|
|
|
|
Chevy Chevelle - 1972-73 |
4.1l 250 L6, 5.0l 307 V8 |
|
|
|
|
|
Chevy El Camino / Caballero - 1975-77 |
4.1l 250 L6 |
|
|
|
|
|
Chevy El Camino / Caballero - 1979-87 |
3.8l 231 V6, 3.8l 229 V6, 4.3l 262 V6 |
|
|
|
|
|
Chevy Impala - 1971 -73 |
4.1l 250 L6 |
|
|
|
|
|
Chevy Malibu - 1975-77 |
4.1l 250 L6 |
|
|
|
|
|
APPLICATION |
ENGINES |
|
|
|
|
|
Chevy Malibu - 1978-83 |
3.8l 231 V6, 3.8l 229 V6 |
|
|
|
|
|
Chevy Monte Carlo - 1972-73 |
5.7l 350 V8 |
|
|
|
|
|
Chevy Monte Carlo - 1979-88 |
3.8l 231 V6, 3.8l 229 V6, 4.3l 262 V6, 3.8l 231
V6, |
|
|
|
|
|
Chevy Nova - 1968-69 |
3.7l 225 V6, 5.0l 307 V8, 5.7l 350 V8 |
|
|
|
|
|
Chevy Nova - 1972-79 |
4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8, 4.3l 262
V8 |
|
|
|
|
|
Chevy Nova - 1970-71 |
5.0l 307 V8, 5.7l 350 V8, 4.1l 250 L6 |
|
|
|
|
|
Chevy Nova - 1972-74 |
4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8 |
|
|
|
|
|
Olds 98 -1981-83 |
4.1l 252 V6 |
|
|
|
|
|
Olds Cutlass Calais - 1981-1983 |
3.8l 231 V6 |
|
|
|
|
|
Olds Cutlass - 1980-87 |
3.8l 231 V6, |
|
|
|
|
|
Olds Cutlass Supreme - 1980-87 |
3.8l 231 V6 |
|
|
|
|
|
Olds Cutlass Cruiser - 1980-83 |
3.8l 231 V6 |
|
|
|
|
|
Olds Omega - 1973-79 |
4.1l 250 L6, 5.0l 305 V8 |
|
|
|
|
|
Olds Omega - 1973 |
4.1l 250 L6 |
|
|
|
|
|
Olds Delta 88/ Eighty Eight/ Royal -1979 |
3.8l 231 V6 |
|
|
|
|
|
Pontiac Bonneville - 1980-86 |
3.8l 231 V6, 4.1l 252 V6,4.3l 262 V6 |
|
|
|
|
|
Pontiac Catalina - 1980-81 |
3.8l 229 V6, 3.8l 231 V6 |
|
|
|
|
|
Pontiac Firebird / Trans Am - 1970-76 |
4.1l 250 L6 |
|
|
|
|
|
Pontiac Le Mans- 1972 |
4.1l 250 L6 |
|
|
|
|
|
Pontiac Le Mans- 1980-81 |
3.8l 229 V6, 3.8l 231 V6 |
|
|
|
|
|
APPLICATION |
ENGINES |
|
|
|
|
|
Pontiac Parisienne-1984-86 |
3.8l 231 V6, 4.3l 262 V6 |
|
|
|
|
|
Pontiac Phoenix-1978-79 |
5.0l 305 V8, 5.7l 350 V8 |
|
|
|
|
|
Pontiac Ventura-1972-76 |
4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8 |
|
|
|
|
|
Pontiac Ventura - 1972-74 |
4.1l 250 L6, 5.0l 307 V8, 5.7l 350 V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
