CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

Fill Neck

TRANS COOLER

MOUNTING TYPE

18 7/8" x 28 1/4"

20 7/8" x 33 3/4"

In - Driver, Out - Passenger

In - 1 1/2, Out - 1 5/8

Yes

1/2-20 Straight Thread, Inverted Flare

Saddle Mount

APPLICATION

ENGINES

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

Chevy Blazer/Jimmy - 1973-78

400ci v8, 454ci V8

2 1/4"

2 1/2"

Chevy Blazer/Jimmy - 1979

305ci V8, 350ci V8, 400ci V8, 454ci V8

Chevy Blazer/Jimmy - 1980

305ci V8, 350ci V8, 454ci V8

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

Chevy Blazer/Jimmy - 1981-91

250ci L6, 305ci V8, 350ci V8

1 1/2"

2 1/2"

Chevy C/K Series- 1973-80

305ci V8, 350ci V8, 400ci V8, 454ci V8

Chevy C/K Series- 1981-87

305ci V8, 350ci V8, 454ci V8

4 ROW CORE THICKNESS

4 ROW TANK THICKNESS

Chevy Suburban - 1973-75

454ci V8

2 3/4"

3 1/8"

Chevy Suburban - 1976-79

305ci V8, 350ci V8, 400ci V8, 454ci V8

Chevy Suburban - 1980-87

305ci V8, 350ci V8, 454ci V8

Chevy Suburban - 1988-91

350ci V8
