CORE DIM  (H x W)

OVERALL  (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

MOUNTING TYPE

BRACKET SPECS

16 1/8 x 24 1/2

23 x 26 3/4

IN-DRIVER /OUT-PASS

IN-1 1/2  /OUT- 1 1/2

Metric 12-1.25

BRACKET MOUNT

Vert - 7 7/8  Horizontal - 25 7/8

APPLICATION

ENGINES

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

NISSAN 280ZX 1981-83

2.8 L6

2"

2 3/4"

2 ROW CORE THICKNESS

1 1/2"
