CORE DIM  (H x W)

OVERALL  (H x W)

HOSE LOCATIONS

HOSE FITTINGS

FILL NECK

TRANS COOLER

MOUNTING TYPE

15 x 19 7/8

17 1/4 x 25 1/4

In - Driver, Out - Passenger

In - 1 3/8, Out - 1 3/8

Yes

1/2-20 Straight Thread, Inverted Flare

Saddle Mount

APPLICATION

ENGINES

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

Pontiac Fiero - 1984

2.5l L4

2 1/4"

2 1/2"

Pontiac Fiero - 1985-88

2.5l L4, 2.8l V6

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

DESIGNED FOR A V8 CONVERSION

1 1/2"

2 1/2"
