Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
18 7/8" x 34" |
21 1/4" x 40
1/4" |
In - Driver, Out -
Passenger |
In - 1 3/4",
Out - 1 3/4" |
Yes |
1/2-20 Straight
Thread, Inverted Flare |
N/A |
Saddle Mount |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1987 - 1991 Chevrolet Blazer |
6.2L 379ci V8 |
|
|
|
2 1/4" |
3" |
|
1982 - 1986 Chevrolet C10 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet C10 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1988 - 1991 Chevrolet C1500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet C20 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet C20 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1988 - 1991 Chevrolet C2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet C30 |
6.2L 379ci V8 |
|
|
|
|
|
|
1988 - 1991 Chevrolet C3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet K10 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet K10 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1988 - 1991 Chevrolet K1500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet K20 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet K20 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1988 - 1991 Chevrolet K2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet K30 |
6.2L 379ci V8 |
|
|
|
|
|
|
1988 - 1991 Chevrolet K3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 Chevrolet K5 Blazer |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1989 Chevrolet P20 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 Chevrolet P30 |
6.2L 379ci V8, 7.4L
454ci V8 |
|
|
|
|
|
|
1987 Chevrolet R10 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1988 Chevrolet R10 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1989 - 1991 Chevrolet R1500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1988 Chevrolet R20 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1988 Chevrolet R20 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1989 Chevrolet R2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1989 - 1991 Chevrolet R2500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1988 Chevrolet R30 |
6.2L 379ci V8 |
|
|
|
|
|
|
1989 - 1991 Chevrolet R3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 Chevrolet V10 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1988 Chevrolet V10 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1989 - 1991 Chevrolet V1500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 Chevrolet V20 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1988 Chevrolet V20 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1989 - 1991 Chevrolet V2500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1988 Chevrolet V30 |
6.2L 379ci V8 |
|
|
|
|
|
|
1989 - 1991 Chevrolet V3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC C1500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 GMC C1500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC C2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 GMC C2500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC C3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC Jimmy |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC K1500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 GMC K1500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC K2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1986 GMC K2500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC K3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1989 GMC P2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1982 - 1991 GMC P3500 |
6.2L 379ci V8, 7.4L
454ci V8 |
|
|
|
|
|
|
1987 GMC R1500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1991 GMC R1500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1989 GMC R2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1991 GMC R2500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1991 GMC R3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 GMC V1500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1991 GMC V1500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 GMC V2500 |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1991 GMC V2500 Suburban |
6.2L 379ci V8 |
|
|
|
|
|
|
1987 - 1991 GMC V3500 |
6.2L 379ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
