CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

TRANS COOLER

MOUNTING TYPE

SHROUD BRACKET

17 1/4 x 26 1/4

20 x 32

In - Driver, Out - Passenger

In - 1 3/8, Out - 1 5/8

1/2-20 Straight Thread, Inverted Flare

Saddle Mount

Vert - 22 3/8, Horizontal - 17 1/2

APPLICATION

ENGINES

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

Pontiac Firebird/ Trans Am - 1982-84

2.5l L4, 305ci V8

2 1/4"

2 1/2"

Pontiac Firebird/ Trans Am - 1985-86

305ci V8

Pontiac Firebird/ Trans Am - 1987-88

305ci V8, 350ci V8

2 ROW CORE THICKNESS

Pontiac Firebird/ Trans Am - 1989-92

3.8l V6, 305ci V8, 350ci V8

1 1/2"

Chevy Camaro - 1982-84

2.5l L4, 305ci V8

Chevy Camaro - 1985-86

305ci V8

4 ROW CORE THICKNESS

Chevy Camaro - 1987-89

305ci V8, 350ci V8

2 3/4"

Chevy Camaro - 1990-92

3.1l V6, 305ci V8, 350ci V8
