Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 1/4" x 26 1/4" |
20" x 32" |
In - Driver, Out - Passenger |
In - 1 3/8", Out - 1
5/8" |
Yes |
1/2-20 Straight Thread, Inverted Flare |
Saddle Mount |
Vert - 22 3/8", Horizontal - 17 1/2" |
|
|
|
|
|
|
|
|
|
|
This Part is Manual Transmission Only |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
|
2 1/4" |
2 1/2" |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
|
|
Pontiac Firebird/ Trans Am - 1982-84 |
2.5l L4, 305ci V8 |
|
|
|
|
|
Pontiac Firebird/ Trans Am - 1985-86 |
305ci V8 |
|
|
|
|
|
Pontiac Firebird/ Trans Am - 1987-88 |
305ci V8, 350ci V8 |
|
|
|
|
|
Pontiac Firebird/ Trans Am - 1989-92 |
3.8l V6, 305ci V8, 350ci V8 |
|
|
|
|
|
Chevy Camaro - 1982-84 |
2.5l L4, 305ci V8 |
|
|
|
|
|
Chevy Camaro - 1985-86 |
305ci V8 |
|
|
|
|
|
Chevy Camaro - 1987-89 |
305ci V8, 350ci V8 |
|
|
|
|
|
Chevy Camaro - 1990-92 |
3.1l V6, 305ci V8, 350ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
