Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
18" x 25 1/2" |
22 7/8" x 30
1/8" |
In - Driver, Out -
Passenger |
In - 1 1/2",
Out - 1 3/4" |
Yes |
1/8-27 NPT |
29" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1979 - 1989 Dodge D100 |
3.9L 239ci V6, 5.2L
318 V8, |
|
|
|
2 1/4" |
2 1/2" |
|
5.9L 360ci V8 |
|
|
|
|
|
|
1979 Dodge D100 Panel |
5.9L 360ci V8 |
|
|
|
2 Row Core Thickness |
2 Row Tank Thickness |
|
1979 - 1991 Dodge D150 |
3.9L 239ci V6, 5.2L 318 V8, |
|
|
|
1 5/8" |
2" |
|
5.9L 360ci V8 |
|
|
|
|
|
|
1979 - 1980 Dodge D200 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
1981 - 1993 Dodge D250 |
3.9L 239ci V6, 5.2L 318 V8, |
|
|
|
|
|
|
5.9L 360ci V8 |
|
|
|
|
|
|
1979 - 1980 Dodge D300 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
1979 - 1993 Dodge D350 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
5.9L 359ci L6 |
|
|
|
|
|
|
1979 - 1981 Dodge D400 |
5.9L 360ci V8 |
|
|
|
|
|
|
1979 - 1981 Dodge D450 |
5.9L 360ci V8 |
|
|
|
|
|
|
1979 - 1991 Dodge Ramcharger |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
1980 Dodge RD200 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
1984 - 1989 Dodge W100 |
3.9L 239ci V6, 5.2L 318 V8, |
|
|
|
|
|
|
5.9L 360ci V8 |
|
|
|
|
|
|
1979 - 1993 Dodge W150 |
3.9L 239ci V6, 5.2L 318 V8, |
|
|
|
|
|
|
5.9L 360ci V8 |
|
|
|
|
|
|
1979 - 1980 Dodge W200 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
1981 - 1993 Dodge W250 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
5.9L 359ci L6 |
|
|
|
|
|
|
1979 - 1980 Dodge W300 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
1981 - 1993 Dodge W350 |
5.2L 318 V8, 5.9L 360ci V8 |
|
|
|
|
|
|
5.9L 359ci L6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
