CORE DIM (H x W)
OVERALL (H x W)
HOSE LOCATIONS
HOSE FITTINGS
FILL NECK
TRANS COOLER
MOUNTING TYPE
17 5/8" x 23 5/8"
18 1/4" x 27 3/4"
In - Driver, Out - Passenger
In - 1 3/8", Out - 1 5/8"
No
1/2-20 Straight Thread, Inverted Flare
Saddle Mount
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
1991 - 1996 Corvette
5.7 V8
2 1/4"
2 1/2"
2 ROW CORE THICKNESS
2 ROW TANK THICKNESS
1 5/8"
2 1/2"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 1/8"
