CORE DIM (H x W)	OVERALL (H x W)	HOSE LOCATIONS	HOSE FITTINGS	TRANS COOLER	FILL NECK	MOUNTING TYPE	BRACKET SPECS
	23 3/4 x 31 1/8	30 7/8 x 33 3/4	In - Passenger, Out - Driver	In - 1 3/4, Out - 2	1/8-27 NPT	Yes	Bracket Mount	Ver - 7 1/4, Horizontal - 32 1/8
	APPLICATION		ENGINES				3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	F-Series Pickups 1983-94		6.9/7.3 V8 Diesel Motor				2 1/4"	3"
							2 ROW CORE THICKNESS	2 ROW TANK THICKNESS
							1 5/8"	3"
