Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
Fill Neck
Trans Cooler
Mounting Specs
Mounting Type
15 3/4" x 23 7/8"
20 7/8" x 26 1/8"
In - Passenger, Out - Passenger
IN - 1 1/4", Out - 1 1/2"
Yes
1/2-20 Inverted Flare
N/A
OEM Style
Application
Engines
3 Row Core Thickness
3 Row Tank Thickness
1981 - 1990 Toyota Land Cruiser
2.4L L4, 3.4 209ci L4
2 1/4"
2 3/4"
4.0L 6L, 4.2L 258ci L6
Note Designed for LS Motor Swap
