CORE DIM (H x W)
OVERALL
(H x W)
HOSE LOCATIONS
HOSE FITTINGS
FILL NECK
TRANS COOLER
MOUNTING TYPE
17 x 27 1/2
18 5/8 x 31 5/8
In - Driver, Out - Passenger
In - 1 1/2, Out - 1 3/4
No
1/2-20 Straight Thread, Inverted Flare
Saddle Mount
APPLICATION
ENGINES
3 ROW CORE THICKNESS
3 ROW TANK THICKNESS
Chevy Corvette - 1969 - 72
7.0 427, 7.4 454 V8
"BIG BLOCK"
2 1/4"
3 3/8"
4 ROW CORE THICKNESS
4 ROW TANK THICKNESS
2 3/4"
3 3/8"
