Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
17 1/2" x 23 1/2" |
22 7/8" x 25 1/8" |
In - Passenger, Out - Driver |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/8-27 NPT |
N/A |
Saddle Mount |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1968-1969
Ford Fairlane |
6.4L 390ci V8, 7.0L 427ci V8, 7.0L 428ci V8 |
|
|
2 1/4" |
2 1/2" |
|
1968 - 1969
Ford Ranchero |
6.4L 390ci V8, 7.0L 428ci V8 |
|
|
|
|
|
1968 - 1969
Ford Torino |
6.4L 390ci V8, 7.0L 427ci V8, 7.0L 428ci V8 |
|
|
|
|
|
1968 - 1969
Mercury Comet |
6.4L 390ci V8, 7.0L 427ci V8, 7.0L 428ci V8 |
|
|
|
|
|
1968 - 1969
Mercury Cyclone |
6.4L 390ci V8, 7.0L 427ci V8, 7.0L 428ci V8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
