Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Type |
Bracket Specs |
Shroud Mount Width |
|
|
18 1/8 x 25 7/8 |
24 5/8 x 30 |
In - Driver, Out - Driver |
In - 1 1/2, Out - 1 3/4 |
Yes |
1/8-27 NPT |
Bracket |
28 3/8" |
27 5/8" |
|
|
|
Application |
ENGINES |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
|
1966 - 1969 Dodge Charger Base |
5.2L 318ci SB V8 |
|
2 1/4" |
2 1/2" |
|
|
1967 - 1969 Dodge Charger R/T |
5.2L 318ci SB V8 |
|
|
1969 Dodge Charger 500 |
5.2L 318ci SB V8 |
|
4 Row Core Thickness |
4 Row Tank Thickness |
|
|
1969 Dodge Charger SE |
5.2L 318ci SB V8 |
|
2 3/4" |
3 1/8" |
|
|
NOTE: Verify Shroud
Mount Width Before Ordering |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
