CORE DIM (H x W)

OVERALL (H x W)

HOSE LOCATIONS

HOSE FITTINGS

FILL NECK

TRANS COOLER

MOUNTING TYPE

15 3/4 x 25

21 3/4 x 25 1/2

In - Driver, Out - Passenger

In - 1 1/2, Out - 1 3/4

Yes

1/2-20 Straight Thread, Inverted Flare

Saddle Mount

APPLICATION

ENGINES

2 ROW CORE THICKNESS

2 ROW TANK THICKNESS

1965-1967 Pontiac GTO

6.4L 389ci V8, 6.6L 400ci V8

1 1/2"

2 1/2"

1965-1967 Pontiac LeMans

5.3L 326ci V8

1965-1967 Pontiac Tempest

5.3L 326ci V8

3 ROW CORE THICKNESS

3 ROW TANK THICKNESS

NOTE: Overall Height (Tank to Tank): 20 9/16"

2 1/4"

2 1/2"
