CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
Fill Neck |
TRANS COOLER |
MOUNTING TYPE |
|
15 1/2" x 25" |
21" x 25 1/2" |
In - Driver, Out - Passenger |
In - 1 1/2, Out - 1 3/4 |
Yes |
1/2-20 Straight Thread, Inverted Flare |
Saddle |
|
|
|
|
|
|
|
|
|
APPLICATION |
ENGINES |
|
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
|
1965-1967
Pontiac GTO |
6.4L 389ci V8, 6.6L 400ci V8 |
|
|
1 1/2" |
2 1/2" |
|
1965-1967
Pontiac LeMans |
5.3L 326ci V8 |
|
|
|
|
|
1965-1967
Pontiac Tempest |
5.3L 326ci V8 |
|
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
NOTE: Overall Height (Tank to Tank):
20" |
|
|
2 1/4" |
2 1/2" |
|
|
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
|
2 3/4" |
3 1/8" |
|
|
|
|
|
|
|
|
|
