Core Dim (H x W)
Overall (H x W)
Hose Locations
Hose Fittings
Fill Neck
Trans Cooler
Mounting Specs
Mounting Type
18" x 27 1/2"
21 5/8" x 37 3/4"
In - Driver, Out - Passenger
In - 1 3/4", Out - 1 3/4"
Yes
1/8-27NPT
33 7/8"
Brackets
Application
Engines
3 Row Core Thickness
3 Row Tank Thickness
1985 - 1992 Ford Bronco
4.9L 300ci L6
2 1/4"
2 1/2"
1985 - 1996 Ford F150
4.9L 300ci L6, 3.8L 232ci V6
1985 - 1996 Ford F250
4.9L 300ci L6
1985 - 1996 Ford F350
4.9L 300ci L6
Note: 3 row version of DPI 1454
