CORE DIM  (H x W)	OVERALL  (H x W)	HOSE LOCATIONS	HOSE FITTINGS	Fill Neck	TRANS COOLER	MOUNTING TYPE
	15 3/4 x 24 1/4	19 1/2 x 31 3/4	In - Passenger, Out - Driver	In - 1 1/2, Out - 1 3/4	No	1/4-18 NPT	Pin Mount
	APPLICATION		ENGINES			3 ROW CORE THICKNESS	3 ROW TANK THICKNESS
	Ford Mustang - 1996		4.6l V8 (281ci)			2"	2 1/2"
	*1488 Without Fill Neck*					4 ROW CORE THICKNESS	4 ROW TANK THICKNESS
						2 3/4"	3 1/8"
	No Engine Oil Cooler
