CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
FILL NECK |
TRANS COOLER |
MOUNTING TYPE |
|
|
|
14 3/4 x 26 1/4 |
18 x 32 |
In-Passenger, Out-Passenger |
In/Out: -16ORB (Female) |
Yes |
No |
Pin Mount |
|
|
|
|
LS Engine Swap And Dual Pass for
All Engines Below |
|
|
Does Not Include Engine Oil Cooler |
|
|
|
|
|
|
|
APPLICATION |
ENGINES |
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
|
|
Chevy/GMC S/T Series Pickups/Blazers-1996-2005 |
4.3l 262 V6 |
|
2 1/4" |
2 1/4" |
|
|
Chevy/GMC Blazers/Jimmy-1996-2005 |
4.3l 262 V6 |
|
|
Olds Bravada-1996-2001 |
4.3l 262 V6 |
|
|
S10 V8 Conversion 86-2005 |
Chevy Conversion |
|
|
Isuzu Hombre-1997-2000 |
4.3l 262 V6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
