22 3/8" CORE |
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
| |
CORE DIM (H x W) |
OVERALL (H x W) |
HOSE LOCATIONS |
HOSE FITTINGS |
TRANS COOLER |
FILL NECK |
MOUNTING TYPE |
BRACKET SPECS |
| |
16" x 22 3/8" |
21" x 25 3/4" |
In - Driver, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
1/8-27 NPT |
Yes |
Bracket Mount |
24 1/2" |
| |
|
|
|
|
|
|
|
|
| |
APPLICATION |
ENGINES |
|
|
|
3 ROW CORE THICKNESS |
3 ROW TANK THICKNESS |
| |
Dodge Challenger - 1970-71 |
318ci Small Block V8 |
|
|
|
B CORE 2 1/2" |
2 7/8" |
| |
Dodge Charger - 1970-72 |
318ci Small Block V8 |
|
|
|
|
|
| |
Dodge Coronet - 1970 -73 |
318ci Small Block V8 |
|
|
|
2 ROW CORE THICKNESS |
2 ROW TANK THICKNESS |
| |
Plymouth Barracuda - 1970-73 |
318ci Small Block V8 |
|
|
|
1 5/8" |
2 7/8" |
| |
Plymouth Belvedere - 1970 |
318ci Small Block V8 |
|
|
|
|
|
| |
Plymouth Roadrunner - 1972-73 |
318ci Small Block V8 |
|
|
|
4 ROW CORE THICKNESS |
4 ROW TANK THICKNESS |
| |
Plymouth Satellite - 1971-73 |
318ci Small Block V8 |
|
|
|
2 3/4" |
3 1/8" |
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
