Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
18" x 18 3/8" |
24" x 22 5/8" |
In - Dual, Out - Dual |
In - 1 1/4", Out - 1 3/4" |
Yes |
1/8-27 NPT |
N/A |
Brackets |
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1928 - 1929
Ford Model A |
Flathead V8 Motor Conversion |
|
2 1/2" |
Upper - 4 1/4", Lower - 3" |
|
|
2 Row Core Thickness |
2 Row Tank Thickness |
|
1 1/2" |
Upper - 4 1/4", Lower - 1 7/8" |
|
|
|
|
|
|
|
|
|
|
