Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
22 1/2" x 18" |
28 1/8" x 22 1/8" |
In - Center, Out - Passenger |
In - 1 1/2", Out - 1 3/4" |
Yes |
1/2-20 Straight Thread, Inverted Flare |
21 1/8" |
Brackets |
|
|
|
|
|
|
|
|
|
|
Application |
Engines |
|
|
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1939
Chevrolet JC |
For V8 Conversion (1/2 Ton Pickup) |
|
|
|
2 1/4" |
2 1/2" |
|
1939
Chevrolet JD |
For V8 Conversion (3/4 Ton Pickup) |
|
|
|
|
|
|
1939
Chevrolet VA |
For V8 Conversion (1 Ton Pickup) |
|
|
|
|
|
|
1940
Chevrolet KC |
For V8 Conversion (1/2 Ton Pickup) |
|
|
|
|
|
|
1940
Chevrolet KD |
For V8 Conversion (3/4 Ton Pickup) |
|
|
|
|
|
|
1940
Chevrolet KF |
For V8 Conversion (1 Ton Pickup) |
|
|
|
|
|
|
1940
Chevrolet KP |
For V8 Conversion (1 Ton Pickup) |
|
|
|
|
|
|
1940
Chevrolet WA |
For V8 Conversion (1.5 Ton Pick-up) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
