Core Dim (H x W) |
Overall (H x W) |
Hose Locations |
Hose Fittings |
Fill Neck |
Trans Cooler |
Mounting Specs |
Mounting Type |
|
21 1/2" x 20 3/4" |
27 5/8" x 24
3/4" |
In - Passenger, Out
- Passenger |
In - 1 1/4",
Out - 1 1/2" |
Yes |
1/2-20 Straight
Thread, Inverted Flare |
23 5/8" |
Brackets |
|
|
Application |
Engines |
|
3 Row Core Thickness |
3 Row Tank Thickness |
|
1942 - 1947 Ford 1 Ton Pickup |
2.0L 120ci L4, 3.6L
221ci V8 |
|
2 1/4" |
2 5/8" |
|
3.7L 226ci L6, 3.9L 239ci V8 |
|
|
1942 - 1947 Ford 1/2 Ton Pickup |
2.0L 120ci L4, 3.6L
221ci V8 |
|
|
3.7L 226ci L6, 3.9L 239ci V8 |
|
|
1942 - 1947 Ford 3/4 Ton Pickup |
2.0L 120ci L4, 3.6L
221ci V8 |
|
|
3.7L 226ci L6, 3.9L 239ci V8 |
|
|
1948 - 1952 Ford F1 |
3.7L 226ci L6, 3.9L
239ci V8 |
|
|
4.2L 255ci V8 |
|
|
1948 - 1952 Ford F2 |
3.7L 226ci L6, 3.9L
239ci V8 |
|
|
4.2L 255ci V8 |
|
|
1948
- 1952 Ford F3 |
3.7L 226ci L6, 3.9L
239ci V8 |
|
|
4.2L 255ci V8 |
|
|
Note: Designed for LS Engine Swap |
|
|
|
|
|
|
|
|
|
|
|
|
|
