Core Dim (H x W)	Overall (H x W)	Hose Locations	Hose Fittings	Fill Neck	Trans Cooler	Mounting Specs	Mounting Type
	20 1/2" x 19 5/8"	25 3/4" x 22 5/8"	In - Center, Out - Passenger	In - 1 1/2", Out - 1 1/2"	Yes	1/2-20 Straight Thread, Inverted Flare	21 3/4"	Brackets
	Application		Engine				3 Row Core Thickness	3 Row Tank Thickness
	1947 - 1954 GMC Truck		216ci 3.5L I6				2 1/4"	Upper - 3 7/8", Lower - 2 3/4"
	1947 - 1954 GMC Carry All		235ci 3.9L I6
	1947 - 1954 Panel Truck		261ci 4.3L I6				4 Row Core Thickness	4 Row Tank Thickness
							2 3/4"	Upper - 3 7/8", Lower - 3 1/8"
