Core Dim (H x W)	Overall (H x W)	Hose Locations	Hose Fittings	Fill Neck	Trans Cooler	Mounting Specs	Mounting Type
	22" x 22"	27 7/8" x 24"	In - Center, Out - Passenger	In - 1 1/2", Out - 1 3/4"	Yes	1/2-20 Straight Thread, Inverted Flare	23 1/4"	Brackets
	Application		Engines				3 Row Core Thickness	3 Row Tank Thickness
	1949 Oldsmobile Series 78		Chevy Conversion				2 1/2"	Upper - 3 1/8", Lower - 2 3/4"
	1949 Oldsmobile Series 88		Chevy Conversion
	1949 Oldsmobile Series 98		Chevy Conversion
	1950 Oldsmobile 88		Chevy Conversion
